BRAND	Weiss
Product	TC0220T-0000-0000-10
Description	Rotary table
Internal code	IMP3700563
Weight	59
Technical specification	TC 220T rotary indexing table Division: 04 Speed level: J MTM according to customer specification [kgm²]: 17.3 MTM max. (kgm²): 17.3 Rotating time approx. (s): 1.17 Time from start signal to completion approx. 80-130ms greater than rotation time Installation position: normal (MP1) Drive position: DP1 (inside side) Painted in RAL: 7035 increased partial accuracy: no Drive type: BRE024V limit switch voltage 24V-DC PNP Rotary encoder: without (closed with sheet metal) tensioning disc: normal special processing: no Direction of rotation: arbitrary Please note that unprocessed cast surfaces of the enclosure according to DIN ISO 8062 GTB17 are. drive motor: size: 63 V/6 Design: B14 (F120) Brake voltage (V) :24 Motor voltage (V): 230/400 Frequency (Hz): 50 Power (kW): 0.18 speed (min-1): 830 Current (A): 1.7/1.0 Paintwork: black according to UL/CSA approval 20 TD0070A-DE00-0000-00 3 pieces Installation instructions (TC0120G/0150T/0220T/0320T) Country of origin DE The assembly instructions are part of the previous position

Please Contact Us to Order to offer competitive prices and delivery time for Weiss - TC0220T-0000-0000-10 Rotary table number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.
