ASF2-13R--190986R - Steimel Norway (Norge) Sales

BRAND	Steimel
Product	ASF2-13R--190986R
Description	Gear pump unit
Internal code	IMP4430570
Custom code	84136039
Technical specification	A-SF2/13R-VLMF 1.1 kW, 1000, 230/400 V, 50 Hz, IP55, F, IE3, B3/B5, ABB Gear pump unit SF 2/13 R - VLMF Item no. ASF2-13R—190986R Dimensional drawing DPA052-190986R spare parts list DET052013R—150R suction and pressure connection G 1/SAE 1 Material design: Housing parts EN-GJL-250 (GG-25) pinion shafts 16 Mn Cr S 5, nitrided helical Multilayer MD storage Shaft seal radial shaft seal elastomers FKM Lubrication oil pumped Viscosity 50-5000 cSt Flow rate approx. 12 l/min pressure 5 bar rotational speed 950 rpm Rotation direction right coupling BKUA040-1424-301 BLA052200110LA21 pump rack 3-phase standard motor, ABB Item no. LDM090-06-094 (ABB) engine data Power P 1.1 kW Speed n 1000 rpm Voltage U 230/400 volts frequency f 50 Hz protection class IP55 insulation class F IE3 premium efficiency class B3/B5 design Aggregate coat primed HDO058-green Rehearsal yes, with HLPD 46 Nameplate ETY924-D-E—PE02

Please Contact Us to Order to offer competitive prices and delivery time for Steimel - ASF2-13R--190986R Gear pump unit number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
