SF 4/80 RD - LFM  - Steimel Norway (Norge)  Sales

BRAND Steimel
Product SF 4/80 RD - LFM
Description Gear pump unit
Internal code IMP431333
Weight 1
Technical specification ASF4-80RD-210538R A-SF4/80RD-LFM, pump unit, 2-16 bar 5.5 kW, 1500, 400/690V, IE3, 50Hz, IP55, Iso.F, B5 Product no.: ASF4-80RD-210538R Dimensional Drawing: DPA054D-170680R Spare parts list: DET054080RD—150R Suction and pressure connection: SAE 2 (DN 50) Materials: Housing Parts: EN-GJL 250 (GG-25) Waves: 16mnCRS5 Gears: EN GJS-400-15 (GGG-40), ionized helical Storage: Multilayer MD Shaft sealing: radial shaft seal Elastomers: FKM Pumped medium: lubricating oil Viscosity: 50-5000 cSt Flow rate: 112 l/min Pressure: 5 bar Speed: 1450 rpm Pressure Relief Valve Setting range: 2-16 bar Opening pressure: 8 bar Direction of rotation: right Clutch: BKUA065-2438-301 Pump carrier with foot: BLF054300168-01 (foot IJN300) 3-phase motor: LDM132-04-904 (birch dent) Power: 5.5 kW Rotational speed: 1500 rpm Voltage: 400/690 volts Frequency: 50 Hz Degree of protection: IP 55 Insulation class: F Premium efficiency class: IE3 Design: B 5 Aggregation screed: primer HDO058 Trial: yes Identification plate: ETY924-D-E-PE02

Please Contact Us to Order to offer competitive prices and delivery time for Steimel - SF 4/80 RD - LFM Gear pump unit number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
