BRAND | Sirai |
Product | L182B01-ZB10A-G1/2-230VAC |
Description | Solenoid valve |
Internal code | IMP4011555 |
Custom code | 8481809990 |
Technical specification | Number of ways 2-way (2/2) Control type pre-controlled (indirectly operated) Switching function closed without current (N.C.) Description L182B01-ZB10A-G1/2-230VAC Model SIRAI/ASCO series L182 Material brass Special feature Without manual operation ATEX approval no approval Connection size 1/2 inch Connection type G thread DIN 259/ISO 228 Nominal size DN13.5 Voltage 230 Volt AC (~) Power consumption 6VA Electrical connection device plug type B industry Bobbin class class F NBR seal Nominal pressure 0.35-16bar Medium temperature -10°C to +90°C Opening time 70 msec Closing time 600 msec Kv/flow factor 3.80 m³/h Viscosity medium 37 cSt Installation length 66 mm |
Please Contact Us to Order to offer competitive prices and delivery time for Sirai - L182B01-ZB10A-G1/2-230VAC Solenoid valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
