BRAND	LANBAO
Product	LE40XZSN20SBB-D
Description	Inductive Sensor
Internal code	IMP3929354
Technical specification	sensing distance, approx.4mm Function Standard Mounting Non-flush Sensing distance 20mm Assured distance 0…16mm Standard target Fe 60601t Retangular size 4040140mm Output ways AC/DC2 line Output status NO/NC Residual voltage AC:≤10V DC:≤8V Supply voltage 20…250VAC/DC Load current AC:≤300mA DC:≤100mA Switching frequency AC:20Hz DC:100Hz Assured distance ≤±10% Hysteresis range 1…20% Repeat accuracy ≤3% Ambient temperature -25℃…70℃ Ambient humidity 35-95%RH Leakage current AC:≤3mA DC:≤1mA Withstand voltage 1000V/AC 50/60Hz 60s Insulation resistance ≥50MΩ(500VDC) Vibration resistance Complex amplitude 1.5mm 10…50Hz(X,Y,Z 2 hours at each direction) Protection degree IP 67 Output indicator Yellow LED Housing material PBT Certfication CE Connection Terminal

Please Contact Us to Order to offer competitive prices and delivery time for LANBAO - LE40XZSN20SBB-D Inductive Sensor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.
