VX5 504 B2 EX22  - Verlinde Norway (Norge)  Sales

BRAND Verlinde
Product VX5 504 B2 EX22
Internal code IMP4923000
Technical specification VX5 504 B2 EX22 EUROCHAIN VX EX 22 Rated capacity 500 kg Height of lift 3 m Load chain Galvanized Reeving 01 Hoisting speed 4 / 1 m/min Hoisting motor power 0.72 KW Hoist duty group M5 ATEX Ex-Marking EX II 3D Ex h tc IIIC T120°C Dc Hoist suspension Bracket long Trolley type None Main voltage 400 V Phase 3-Phases Description: Frequency 50 Hz Control voltage 48 V Pendant cable length 2.5 m Chain bag Yes Hoisting motor - nominal current 2.4/1.6 A Hoisting motor - starting current 7.2/2.35 A Equipment category 3D Suitable for hazardous area Zone 22 Ex-norm ATEX Mechanical overload device Friction torque limiter Hoisting limit switch Electrical upper & lower limit switch (2 steps) Paint 5 years guaranteed RAL 7021 Control pendant ATEX 2 button pendant with emergency stop, IP65 rated Standard maximum humidity 90 % Overheating protection for the complete equipment Included C-dimension (headroom) 436 mm Standard temperature range -20°C to +40°C with rated load and speed IP66 protection IP66 on hoist panel, hoisting motor, pendant (std) Chain lubrication Grease Number of documents in package 1 Language of documents English (EN) Document delivery Documents to be shipped with the materia

Please Contact Us to Order to offer competitive prices and delivery time for Verlinde - VX5 504 B2 EX22 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
