BRAND | Settima |
Product | TB440LS2 (250-500 cSt)RF2 |
Description | screw pump |
Internal code | IMP4360615 |
Custom code | 84136070 |
Technical specification | GR60 SMT 16B 440L S2 RF2 Q/P (1450 rpm; 46 mm²/s; 10 bar) =218.65 l/min/5.4 kW, NPSH = 2.63 mWS Q/P (1450 rpm; 257.6 mm²/s; 10 bar) =223.03 l/min/6.56 kW, NPSH = 3.37 mWS Settima product number: TB440LS2 (250-500 cSt) RF2 GR60 = frame size SMT 16B = pressure level 40 bar 440L = nominal flow with ø32mm cylindrical shaft for installation with pump carrier and coupling aluminum housing S2 = option for high viscosities (250-500 cSt), poor efficiency RF2 = internal fixed pressure relief valve (10 bar) SAE pressure connection 21/2 3000psi Standard suction housing with SAE connection 3 3000psi NBR sealing material |
Discover the superior quality and performance of the Settima TB440LS2 (250-500 cSt)RF2 with Impexron GMBH in Norway (Norge) . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The TB440LS2 (250-500 cSt)RF2 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of TB440LS2 (250-500 cSt)RF2 :
At Impexron GMBH , we offer the TB440LS2 (250-500 cSt)RF2 at competitive prices and with the fastest delivery times across Norway (Norge) . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the TB440LS2 (250-500 cSt)RF2 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Settima products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
