BRAND | Josef Emmerich |
Product | SP511S |
Internal code | IMP4952475 |
Technical specification | Piston diaphragm pump type: SP511S Design: simple-acting as a horizontal single-cylinder machine with vertical membrane housing Pump technical data: flow rate (m³/h): 4... 0, automatic regulation for filter press charging Delivery pressure (bar): 15 Piston diameter (mm): 120 Piston stroke (mm): 90 Stroke rate (min-1): 74 Valve design: ball valve with inspection opening and replaceable valve seat valve size DN: 50 Mitl. valve flow speed (m/s): 1.27 with a flow rate of 4 m³/h Pump head design: membrane housing with separate membrane housing cover for easy revision of the membrane, without that pipes and/or attachments must be dismantled Membrane design: Double membrane, designed as a large-sized flat membrane with integrated break indicator Components in contact with media: Pump housing and valves: cast iron Pulsation damper: steel, P235GH (St 37-2) Membrane: Perbunan (NBR), diameter 350 mm Valve seat: Vulkollan (polyurethane) Valve ball: Vulkollan with core, Ø 80 mm EK-A2-1245.2 1 FCA double membrane Stk (flat membrane) Ø 350 mm, Perbunan (NBR) Net weight per unit [kg]: 1,200 Product tariff no.: 40169997 Country of origin: DE 3 12338701 2 FCA valve seat Stk DN50, Vulkollan (PUR) Net weight per unit [kg]: 0.320 Product tariff no.: 84139100 Country of origin: DE 4 868001 2 FCA valve ball Stk Ø 80mm, polyurethane with core Net weight per unit [kg]: 1.234 Product tariff no.: 84139100 Country of origin: DE |
Please Contact Us to Order to offer competitive prices and delivery time for Josef Emmerich - SP511S number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
