BRAND | Nord |
Product | SK02050AF-80LP/4 TF |
Description | Spur wheel worm motor |
Internal code | IMP4868791 |
Technical specification | Product name Spur gear worm motor Motor speed 1.415 rpm Translation 19.42 Output speed 73,000 rpm Operating factor 1.80 Output torque M2 (Nm) 81.50 Power (kW) 0.750 Voltage (V) 230/400 Frequency (Hz) 50 Efficiency class IE3 S1 operating mode Motor protection class IP55 Insulation class F Rated current 1 (AMP) 3.10 Rated current 2 (AMP) 1.79 cosine 1 0.72 M5 transmission design Housing type hollow shaft flange B5 Wave measure 25H7 Flange diameter (mm) 200 Flange position flange at A Ventilation open, with transport lock Cold conductor thermal motor protection, 3x155°C Circuit type star Terminal box layer/cable insert met 3/I Lubricant type Synth. ISO VG 680 oil CLP PG 680 oil grade Lubricant quantity (l) 0,750 Shade 5010 gentian blue Paint type solid color Basic painting instructions (2) CE logo Yes CCC logo No Mexico certificate NOM No UL No CSA No DoE CC No CSA ev No Alto Rendimento No Korea Energy Label No |
Please Contact Us to Order to offer competitive prices and delivery time for Nord - SK02050AF-80LP/4 TF Spur wheel worm motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
