Buy SF 2/20 RD - VLFM from Steimel in Norway (Norge)

BRAND	Steimel
Product	SF 2/20 RD - VLFM
Description	pump
Internal code	IMP4282734
Custom code	84136039
Technical specification	ASF2-20RD-171081R A-SF2/20RD-VLFM, pump unit, 2-20 bar 1.5 kW, 1500, 230/400V, IE3, 50Hz, IP55, B5, electr. NEMA Product no.: ASF2-20RD-171081R Dimension sheet: DPA052D-090LFM-R33 Spare parts list: DET052020RD—165R Suction and pressure connection: G 1/SAE 1 Housing Parts: EN-GJL-250 (GG-25) Sprocket shafts, noise.: 16mnCRS5, Egh., inclined. Storage: Multilayer MD Shaft sealing: radial shaft seal Elastomers: FKM Pumped medium: lubricating oil Viscosity: 50 - 5000 cSt Temperature: 10 - 60°C Flow rate: approx. 28.4/34 l/min. Pressure: 5 bar Speed: 1410/1692 rpm Pressure Relief Valve Opening pressure: 8 bar Adjustment range: 2-20 bar Direction of rotation: right Trial: yes, with HLPD 46 Clutch: BKUA040-1424-301 Pump carrier with foot: BLF052200110LA21 3-phase motor: LDM090-04-217 (birch dent) Engine data: Power 1/2:1.5/1.8 kW Speed 1/2:1500/1800 rpm. Voltage/frequency 1:230/400 volts at 50Hz Voltage/frequency 2:266/460 volts at 60Hz Efficiency class: IE3 Degree of protection: IP 55 Insulation class: F Special feature: electrical according to NEMA Design: B 5 Aggregation coat: primed HDO058 - green Identification plate: ETY924-D-E—PE02

Discover the superior quality and performance of the Steimel SF 2/20 RD - VLFM with Impexron GMBH in Norway (Norge) . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The SF 2/20 RD - VLFM is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of SF 2/20 RD - VLFM :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At Impexron GMBH , we offer the SF 2/20 RD - VLFM at competitive prices and with the fastest delivery times across Norway (Norge) . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose Impexron GMBH ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the SF 2/20 RD - VLFM ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply Steimel products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
