BRAND | Steimel |
Product | PSF3/25RD-122126R / P-SF3/25RD-VLF |
Internal code | IMP4459227 |
Custom code | 84136039 |
Technical specification | P-SF3/25RD-VLF, gear pump, 2-18 bar EUR 1,906.74 1,906.74 FKM, suitable for motor size IEC 090, B5 Gear pump: SF 3/25 RD - VLF Product no.: PSF3/25RD-122126R Dimension sheet: DPA053D-090LFM-R31 Spare parts list: DET053025RD--165R Suction and pressure connection: SAE 1 ½ Housing parts: EN-GJL-250 (GG-25) Pinion shafts, noiseless: 16MnCrS5, egh., angle-toothed Storage: multi-layer MD Shaft sealing: radial shaft sealing ring Elastomers: FKM Delivery medium: ISO VG 320 lubricating oil Viscosity: 50 - 5000 cSt Temperature: 18-80°C Flow rate: approx. 35/42 l/min. Pressure: 5 bar Speed: 1450/1740 rpm. Pressure relief valve Opening pressure: 6 bar Direction of rotation: right Test run: yes, with HLPD 46 Coupling: BKUA040-1924-301 Pump carrier with foot: BLF053200118LA21 suitable for three-phase motor Type//Size: IM B 5/V 1//IEC 90 Paint: primed Type plate: ETY924-D/E--PE01 |
Please Contact Us to Order to offer competitive prices and delivery time for Steimel - PSF3/25RD-122126R / P-SF3/25RD-VLF number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
