BRAND | Aviteq |
Product | 31996 - SAE-GS33-2 |
Description | CONTROL |
Internal code | IMP4919859 |
Custom code | 85365003 |
Technical specification | 80.. 420V 50HZ 25A IP00 85365003 00907071 Dimensions 200 x 230 x 140 mm (HxWxD) VIBTRONIC® -S controller for connecting AVITEQ vibrating conveyors. The swing width of the conveyor can be adjusted continuously on the connection device become. Delivery rate adjustment range from close to 0 to 100%. With a complete set of potentiometers for manual swing range adjustment. Electromagnetic compatibility (EMC) in accordance with the applicable EC Directive checked. As network protection, we recommend protection in accordance with the rated current of connected magnetic vibrator (sluggish fuse). Vibration rate SA.. 33.. 2,000 min-1 Display Seven LEDs show the operating status version for installation in central control stations, power cable without incl. control potentiometer set Thyristor protection, via fuse (superflink) Network fluctuation compensation ± 10%, the oscillation width remains constant Network tolerance, allowable voltage ± 10% Frequency ± 0.5% Proportional change in the setpoint range Switch release (continuous contact, potential-free) or voltage signal +24 V (DC) or optocoupler Inputs to external external control variables 0.. 10 V (DC), 0/4.. 20 mA (DC) Sensor input for AViTEQ PA or PAL vibration sensor Remote monitoring outputs, relay output protective function When used on magnetic vibrators with an integrated PAL sensor Version SA.. -2 MV-... P (8V) Version SA.. -2V MVE33-1, MVF33-1, MVF33-2, MVG33-1 (P), MVH33-1 (P) (10V) Voltage and frequency control with impact monitoring When used with an external PA vibration sensor Version SA.. 2S1 payload control Magnetic Vibrator Temperature Switch Monitoring Additional TXAE board required when operating with multiple drives (version.. - 2X) |
Please Contact Us to Order to offer competitive prices and delivery time for Aviteq - 31996 - SAE-GS33-2 CONTROL number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
