Buy SA01-G56M4 / 2010001599 from HIMMEL in Norway (Norge)

BRAND	HIMMEL
Product	SA01-G56M4 / 2010001599
Description	worm gear motor
Internal code	IMP5139297
Weight	7.5
Technical specification	Dimension sheet: SA14 Gearbox design/Type: HIMMEL® worm gear motor/HIMMEL® -worm gear motor Transmission Type/Type: SA01-G56M4 Dimension sheet: SA14 Output speed/ Output speed [1/min; rpm]: 18.00//21.50 Translation/Ratio [i]: 75.00 Color/colour: RAL 7031 Bluegrau/ Blue grey Corrosivity category/corrosion protection: C1: i.a.A. DIN EN ISO 12944-2/HN716.21 Paint layer thickness [μm]: 60-80 Protection class: IP54 Design/mounting position: H-01-B Output torque/Output torque [Nm]: 13.8//11.6 Direction of rotation: left/left [CCW] Output shaft gearbox/ Output shaft [mm; inch]: H14x80 Gearbox bearing: assigned bearings Type of oil/Oil type: CLP PG 460 Synth.oil Oil quantity [l]: 0.11 Shaft material/Shaft material: C45 Gearbox sealing/Sealing: shaft seal ring (WDR)/shaft seal ring Label/Approval\|Identification/Certification: CE Number of poles/poles: 4 Rated frequency/ Nominal frequency [Hz]: 50//60 Rated voltage/nominal voltage [V]: 200-240/380-420//220-277/380-480 Circuit/ Wiring: S100//S100 (D/Y//D/Y) Rated power/nominal power [kW]: 0.09//0.09 Nominal motor speed/Motor speed nom. [1/min; rpm]: 1350//1610 Rated current/Nominal current In [A]: 0.70/0.40//0.70/0.40 CosPhi/CosPHI: 0.68 KK location/Terminal box position: 2A KK version/Terminal box type: plastic/plastic Winding protection/Motor protector: WT 160°C Motor output shaft/Output shaft [mm; inch]: V11x24.5 Sealing motor/Sealing motor: normal/normal Insulation class: F Operating mode/Duty type: S1 Fan/Fan: plastic/plastic

Discover the superior quality and performance of the HIMMEL SA01-G56M4 / 2010001599 with Impexron GMBH in Norway (Norge) . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.

The SA01-G56M4 / 2010001599 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.

Key Features of SA01-G56M4 / 2010001599 :

High Performance: Engineered to deliver exceptional results.
Durable Construction: Built with high-quality materials for long-lasting use.
Innovative Design: Incorporates the latest technology for enhanced efficiency.
Cost-Effective: Offers great value for money with competitive pricing.

At Impexron GMBH , we offer the SA01-G56M4 / 2010001599 at competitive prices and with the fastest delivery times across Norway (Norge) . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.

Why Choose Impexron GMBH ?

Expert Assistance: Get help from our knowledgeable team for all your product-related questions.
Competitive Prices: We offer some of the best prices in the market.
Fast Delivery: Benefit from our efficient delivery network for quick turnaround times.
Customer Satisfaction: Our commitment to customer service ensures a great buying experience.

Get Your Quote Today! Ready to enhance your operations with the SA01-G56M4 / 2010001599 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.

Important Notice: While we supply HIMMEL products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy SA01-G56M4 / 2010001599 by HIMMEL in Norway (Norge)?

You can purchase SA01-G56M4 / 2010001599 by HIMMEL from Impexron GMBH. We serve customers across Norway (Norge), offering competitive prices and reliable service.

What is the price of the SA01-G56M4 / 2010001599?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of HIMMEL in Norway (Norge)?

While we are not the official distributor or seller of HIMMEL in Norway (Norge), we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.

How can I access SA01-G56M4 / 2010001599 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for SA01-G56M4 / 2010001599 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for SA01-G56M4 / 2010001599?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
