| BRAND | Planetroll |
| Product | PD085-ABK040-1AA1 |
| Description | Gearbox |
| Internal code | IMP4812702 |
| Technical specification | 2-stage planetary gearbox type planetdrive PD085 Reduction: i = 40 Twisting game: </= 15 arcmin on the drive side: Flange code: 085BK19 Drive hollow shaft: Ø19 with reducer bushing Ø19/Ø9 Centering: Ø40 4x M4 on TK63 on the output side: Centering: Ø55H7x8 4x M6x12 on TK70 Output shaft: Ø20k6 x 40 Rated torque: T2nENN = 55 Nm at n1 = 3000 1/min Surface: black ring gear |
Please Contact Us to Order to offer competitive prices and delivery time for Planetroll - PD085-ABK040-1AA1 Gearbox number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
