NPS 2 CS820IN-3F - Fischer Norway (Norge) Sales

BRAND	Fischer
Product	NPS 2 CS820IN-3F
Description	Pressure reducing regulator
Internal code	IMP2536502
Weight	10
Technical specification	Type: CS820 Internal Relief: No Registration: Internal Valve Size: NPS 2 End Connection: NPT Body Material: Gray Cast Iron Orifice/Port: 3/8 Inch (9.5 mm) Spring Range: 1 to 2.5 psig (69 mbar to 0.17 bar) Vent Location: D (Std) Body Position: 1 Standard Closing Cap Seal Wire: No Adjusting Screw/Handwheel: Internal w/ Closing Cap (Aluminum) Low Relief S-T-D Spring: No Low Inlet (LIN) Press Option: Not App Pressure Units: psig/ Inch WC PED Nameplate: No Customer Special: Not App Spring Case Material: Aluminum Lower Casing Material: Aluminum Diaphragm Material: NBR Disk Material: NBR Disk Shroud Color: Black Orifice/Port Material: Aluminum Regulator Setpoint: 2 psig (138 mbar) Max Inlet Pressure: 125 psig (8.6 bar) Max Outlet Pressure Setting: 2.5 psig (0.17 bar) Vent Connection: 1 Inch NPT Secondary Seat Protection: No Approximate Shipping Weight(each): 25 lbs (11,3 kg) Supplemental Attribute: Not App

Please Contact Us to Order to offer competitive prices and delivery time for Fischer - NPS 2 CS820IN-3F Pressure reducing regulator number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
