BRAND | Renishaw |
Product | MRA039BC020DSE00 |
Internal code | IMP4714483 |
Custom code | 90319000 |
Technical specification | AksIM RING OD39 2MM C ID20 D SM CPE EZP STD AksIM magnetic ring; 39 mm outer diameter; 2 mm thick; countersunk holes type A (use flat-head fasteners DIN 965 / 7046); 20 mm inner diameter; standard for stamped rings; stamped metal plate with CPE rubber; engraved zero mark; no special requirements (standard) |
Please Contact Us to Order to offer competitive prices and delivery time for Renishaw - MRA039BC020DSE00 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
