BRAND | Steimel |
Product | PKB100IIPR89-124 / A0002000001 |
Internal code | IMP4884634 |
Technical specification | P-KB100-IIPR-DN40 water pump GG-25, with mounting flange, Daimler-Benz Water pump: KB 100-IIPR-DN40 with mounting flange Daimler Item No.: A0002000001 Product no.: PKB100IIPR89-124 Sectional drawing: DSZ100IIPR89-124 Spare parts list: DET100IIPR89-124 Flange connections: DN 40 materials: Housing parts: GG-25 (0.6025) Paddles: GK-CuAl8ni Wave: X22CrNi17 Shaft bearing: rolling bearing (maintenance-free) Mechanical seals: FKM/carbon/chromium molybdenum casting Case seals: paper Direction of rotation: right Pumping medium: fresh water with anticorrosive agent conveying capacity Q max.: 275 l/min. (suction side DN 50) Maximum speed: 4050 rpm p max.: 1.5 bar n Idle: 1345 rpm Performance curve: DLK100IIP-40-02 Priming according to: MTV 5018, page 1-3 Pretreatment: Sa 2.5 sandblasting Primer: RAL 6011, HDO058 layer thickness: 15-20 μm Test run: yes Type shid: ETY924-D-E--PE01 |
Please Contact Us to Order to offer competitive prices and delivery time for Steimel - PKB100IIPR89-124 / A0002000001 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
