IM3536 - Hioki Norway (Norge) Sales

BRAND	Hioki
Product	IM3536
Description	LCR meter
Internal code	IMP3373547
Weight	4.2
Technical specification	LCR METER IM3536 LCR METRE 4HZ-8MHZ General Purpse LCR Meter, DC 4 Hz to 8 MHz Features: Accuracy guarantee range from 1 mΩ, safe for low impedance measurement Internal generation of DC bias measurement possible Worked in a wide range of fields from R & D to production line Accessories: Power cord, CD-R (communication manual, LCR application disc) × 1 Note: ※ For calibration-written products, cancellation is impossible after placing an order. Weight (kg): 4.2 Power supply: AC 100 to 240 V, 50/60 Hz, 50 V A max Display: Color TFT 5.7 inch, touch panel Dimensions (width W × height H × depth D) (mm): 330 × 119 × 230 Function: Comparator, BIN measurement (2 items 10 classification), trigger function, open / short correction, contact check, panel save / load function, memory function Output impedance (Ω): Normal mode: 100, Low Z High accuracy mode: 10 Interface: EXT I / O (handler), / USB / USB memory / LAN / GP-IB / RS-232C, BCD output Display range: Z: 0.00 m to 9.99999 GΩ, Y: 0.000 n to 9.99999 GS, θ: ± (0.000 ° to 180.000 °), Q: ± (0.00 to 9999.99), Rdc: ± (0.00 m to 9.99999 GΩ) D: ± (0.00000 to 9.99999), Δ%: ± (0.000% to 999.999%), others Measurement range: 100 mΩ to 100 MΩ, 10 ranges (All parameters are specified by Z) Measurement frequency: 4 Hz to 8 MHz (setting resolution 5 digit resolution, but minimum resolution 10 mHz) Measurement mode: LCR (measured under a single condition), continuous measurement (continuous measurement under stored conditions) Related materials: Maker catalog Measurement signal level: [[normal mode] of [V mode, CV mode]] 4 Hz to 1.0000 MHz: 10 mV to 5 V (maximum 50 mA), 1.0001 MHz to 8 MHz: 10 mV to 1 V (maximum 10 mA ) [Low Z high precision mode] in [V mode, CV mode]] 4 Hz to 1.0000 MHz: 10 mV to 1 V (maximum 100 mA) [Normal mode] in [CC mode]] 4 Hz to 1.0000 MHz: 10 μA to 50 mA (maximum 5 V), 1.0001 MHz to 8 MHz: 10 μA to 10 mA (maximum 1 V) [Low Z high precision mode] in [CC mode]] 4 Hz to 1.0000 MHz: 10 μA to 100 mA (maximum 1 V) [DC resistance measurement]: fixed at 1 V Parameter: Z, Y, θ, X, G, B, Q, Rdc (DC resistance), Rs (ESR), Rp, Ls, Lp, Cs, Cp, D (tan δ), σ, ε Basic accuracy: Z: ± 0.05% rdg. Θ: ± 0.03 ° (typical value, accuracy guarantee range: 1 mΩ to 200 MΩ)

Please Contact Us to Order to offer competitive prices and delivery time for Hioki - IM3536 LCR meter number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
