BRAND | Binder |
Product | FD-S 56 |
Internal code | IMP4909853 |
Technical specification | (FDS056UL-120V) (9090-0019) Forced Convection Drying and Heating Chamber, 1.9 Cu Ft (55 L), 120V Temperature range 10 °C above ambient temperature to [°C] 250 Temperature variation at 150 °C [± K] 2.6 Temperature fluctuation at 150 °C [± K] 0.5 Heating-up time to 150 °C [min] 20 Air change (approx.) at 100 °C [x/h] 80 Rated Voltage [V] 120 Power frequency [Hz] 60 Nominal power [kW] 1.1 Unit fuse [A] 6.3 Phase (Nominal voltage) 1~ Overall Width [in] 24.19 Overall Height [in] 24.63 Overall Depth [in] 22.73 Wall clearance back [in] 6.3 Wall clearance sidewise [in] 3.94 Unit doors 1 Chamber Width [in] 15.76 Chamber Height [in] 17.34 Chamber Depth [in] 12.21 Interior volume [cu.ft.] 1.9 Net weight of the unit (empty) [lbs] 78 permitted load [lbs] 66 Load per rack [lbs] 33 Energy consumption at 150 °C [Wh/h] 290 Sound-pressure level [dB(A)] 43 Number of shelves (std./max.) 1/3 |
Discover the superior quality and performance of the Binder FD-S 56 with Impexron GMBH in Norway (Norge) . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The FD-S 56 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of FD-S 56 :
At Impexron GMBH , we offer the FD-S 56 at competitive prices and with the fastest delivery times across Norway (Norge) . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the FD-S 56 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Binder products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
