BRAND | Stahl |
Product | 239552 / 6401/522-8508-15-131 |
Description | Longfield lamp |
Internal code | IMP4646357 |
Custom code | 94054940 |
Technical specification | for fluorescent lamps | GRP | explosion-proof | type: 6401/522-8508-15-131 | replacement of type: 6401/522-8508-1511 | lamp tray: clear | tub material: polycarbonate | housing material: polyester resin | design: standard version | housing colour: light grey (RAL 7035) | area of application (zones): 2, 21, 22 | gas explosion protection: II 3 G Ex IIC T4 Gc | Dust explosion protection: II 2 D Ex tb IIIC T80 °C Db | Number of lamps: 2 | Light power: 18 W | Single wire connection max.: 6 mm2 | Flexible connection max.: 4 mm2 | Dimensions (L x W x H) : 700 x 184 x 125 mm | Rated operating voltage AC: 220.00 - 240.00 V | Rated operating voltage DC: 220.00 - 240.00 V | Ambient temperature min.: -30 °C | Ambient temperature max.: +50 °C | Note Through-wiring: max. 3x16 A | Impact resistance (IEC 62262): IK10 | Through-wiring: with 5 conductors 2.5 mm2 | Ballast: elXe | Threaded plate: 2x plastic | Holes: 3 x M25 | included | Cable and cable entries: 2 x M25 Ø 7 — 17 mm | Cable entry material: black polyamide | Sealing plug: 2 x M25 x 1.5 | Material Sealing plug: polyamide black | Installed terminal strip: PE + N + L1 + L2 + L3 |
Please Contact Us to Order to offer competitive prices and delivery time for Stahl - 239552 / 6401/522-8508-15-131 Longfield lamp number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
