BRAND | HIMMEL |
Product | (D120)-H100ICM4-B16N |
Description | Solo motor |
Internal code | IMP4812239 |
Custom code | 85015220 |
Technical specification | Article 2230000755 Dimension picture: H100-XX Output speed: 1440 rpm Protection class: IP54 Design: B5 Paint type: C1 Color: RAL 7031 blue gray 2K Rating plate: adhesive shield film Electrical version: CE Number of pins: 4 Frequency: 50 Voltages: 400/690 V Power: 2.2 kW Circuit: S100 (D/Y) Current: 4.55/2.63 A CosPHI: 0.80 Terminal box position: 1AK Terminal box design: aluminum - M32 Terminal box sealing: rubber Winding protection: PTC160 Warmth class: F Efficiency class: IE3 Operating mode: S1 Brake: B16N Control voltage: 380-440 V Control frequency: AC Power connection: AC network Connection: not on the clipboard Rectifier: half-wave rectifier |
Please Contact Us to Order to offer competitive prices and delivery time for HIMMEL - (D120)-H100ICM4-B16N Solo motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
