BRAND | Combimac |
Product | 54N601/B1N1 |
Description | Ventilator |
Internal code | IMP4806336 |
Technical specification | Paint outside: RAL 5017 blue Paint inside: 2-Comp. black (epoxy) Position at your request. Suitable for frequency regulation. TECHNICAL INFORMATION FAN: - type = 54N601/B1N1 - part number = xxx.xxx - mediumtemp. (max.) = 60ºC - material house = cast iron - material impeller = sheet metal - weight = 100 kg - graphic = 54A601/B1P1 - guideline = EN14986 TECHNICAL INFORMATION MOTOR: - voltage = 400V - 3 ph - power = 3 kW - insulations class = F - frequency = 50 Hz - speed (synchr.) = 3000 rpm - IEC frame = 100L - ambient (max.) = 40ºC - protection class = IP55 - drawing = D.004.772 (only for information) |
Please Contact Us to Order to offer competitive prices and delivery time for Combimac - 54N601/B1N1 Ventilator number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
