BRAND | Stahl |
Product | 214903 / 9160/23-10-10s |
Description | Transmitter power supply |
Internal code | IMP4681062 |
Custom code | 85363010 |
Technical specification | Field circuit Ex i, explosion-proof max. voltage Uo: 27 V Max. current Io: 88 mA Max. power Po: 576 mW Max. voltage Ui: 30 V Max. current Ii: 100 mA Nominal current: 100 mA Power consumption: 2.3 W Number of channels: 2 Connection type: screw terminal input: 0/4... 20 mA with HART output A: passive LFD relay: No SIL: 2 Min. ambient temperature: -20 °C Max. ambient temperature: +70 °C Application area (zones): 2 Gas explosion protection: II 3 (1) G Ex nA [ia Ga] IIC T4 Gc Dust explosion protection: II (1) D [Ex ia Da] |
Please Contact Us to Order to offer competitive prices and delivery time for Stahl - 214903 / 9160/23-10-10s Transmitter power supply number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
