| BRAND | Burkert |
| Product | 20042693 |
| Internal code | IMP4987478 |
| Weight | 1.4 |
| Custom code | 84818079 |
| Technical specification | 2/2-way solenoid valve; servo-controlled 6281-EV-A25,0BBMSGM86-5-230/56-08 * HA17+NA38+PD07 Type 6281 6281 Generation EV Mode of action A 2/2-way; closed in rest position Nominal size 25.0 25 mm BB NBR sealing material Material MS brass GM86 G 1 socket cable connection coil size 5 32 mm Voltage 230 230 volts Frequency 56 50-60 Hz Power consumption 08 8 watts Special feature HA17 manual operation, PA rotary hand operation, rotary lever NA38 coil material insulation material class H PD07 Approved for use on ships, offshore Pressure min 0.20 bar Pressure max 16 bar KV 12 m3/h QNN 13,000 l/min Medium temperature min -10 °C Medium temperature max 80 °C Ambient temperature max 55 °C |
Discover the superior quality and performance of the Burkert 20042693 with Impexron GMBH in Norway (Norge). Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 20042693 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 20042693:
At Impexron GMBH, we offer the 20042693 at competitive prices and with the fastest delivery times across Norway (Norge). Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH?
Get Your Quote Today! Ready to enhance your operations with the 20042693? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Burkert products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
You can purchase :product by :brand from Impexron GMBH.We serve customers across the Norway (Norge), offering competitive prices and reliable service.
What is the price of :product?
For customised pricing and availability, please fill out our or give us a call. We are dedicated to providing solutions that align with your specific requirements.
While we are not the official distributor or seller of :brand in the Norway (Norge), we source our products from reliable channels and offer you original :brand equipment at competitive prices.
You can access catalogues, user manuals, and technical documents for :product on our website. Visit our resources section or contact us directly for specific documents.
We can assist you in contacting the manufacturer to ensure you receive the support you need.
3WAY VALVE 220V
4/2-way pneumatic valve
pneumatic valve
3/2-way Rocker valve, 16mm analysis Type 6606 6606 Action of T 3/2-way; Universal Einset 3/2-way; Universal used Nominal size 1.6 mm 01,6 Seal material FFKM CC Material PD PVDF (polyvinylidene fluoride) DA20 line connection hose hose inner diameter 1.6 mm Coil size 0 Type Based specified Voltage 012 volts 12 Frequency DC DC Power AS 3.4 watts JC09 2 pressed FEP strands 0.2 mm ^ 2 AWG 24, white JW04 cable length 500 mm (19.5 inch) Pressure range -1 - 2 bar Pressure max / Gas 2 bar Weight: kg / pc 0.068
00138100 3/2-WEGE-MAGNETVENTIL; DIREKTWIRKEND
Type 0331 0331 Action of T 3/2-way; Universal Einset 3/2-way; Universal used Nominal diameter 02.0 mm 2 Seal material EPDM AA MS brass material Line connection FB02 flange: Bürkert KL-NR.001-01-18 (32x46) Voltage 024 volts 24
00138192 2/2 WEGE-MAGNETVENTIL SERVOGESTEUERT TYP 5282
SERVO CONTROLLED MAGNETIC VALVE
3/2-way solenoid valve
2/2-way solenoid valve
2/2-way control piston diaphragm valve Type 2030 2030 Control function A closed with spring force Paths / positions 2 2 way / 2-position Nominal diameter 15.0 mm 15 Sealing material AB EPDM (Food Grade) Material PVC PV Line connection KM25 adhesive connection sleeve diameter 20mm Drive Version C PA Drive, VA-threaded socket on the Control air connection Actuator size D DM 50 mm Pressure range 0 - 8.5 bar
2/2-way control piston diaphragm valveType 2031 2031Control function A closed with spring forcePaths / positions 2 2 way / 2-positionNominal diameter 25.0 mm 25Sealing material AB EPDM (Food Grade)Material Stainless steel VAGM86 line connection socket G 1Drive Version C PA Drive, VA-threaded socket on theControl air connectionActuator size F DM 80 mmoutside NO01 glass bead blasted Ra 1.6 microns / Ra64 microinchesNo05 inner glass bead blasted Ra 1.6 microns / Ra64 microinchesPressure range 0 - 10 bar
2/2-way valve with isolating diaphragm for medium up to +100ºC
5/2-way pneumatic valve 10 mm
2/2, G1 / 2 ", brass, NBR, 24VDC, 0256 seri
3/2-way solenoid valve, direct-acting
3/2-way solenoid valve f. aggress. media Type 0121 0121 Mode of action F 3/2-way; distribution valve Nominal width of 6 mm 06,0 Seal material FKM FF Material PD PVDF (polyvinylidene fluoride) GM83 line terminal G 3/8 sleeve Voltage 230 230 Volt Frequency UC direct and alternating current (AC / DC) Power CE 60 Watt suit, 3 watt operation Special CZ05 Internal High Performance JC01 pressed-in tubular cables HO5RN-F3GO, 7 JW10 cable length 3000 mm Pressure range 0 - 2 bar Weight: kg / pc 0.320
solenoid valves
manometer which is part
2/2 way solenoid valve ½ PN1-40 BAR 230V 50-60 HZ 8W
2/2-way solenoid valve; servo piston Type 5404 5404 Action of B 2/2-way; Normally open Nominal diameter 12.0 mm 12 Sealing material EB PTFE seat seal NBR + MS brass material GM84 line terminal G 1/2 sleeve Coil size 5 32 mm Voltage 230 230 Volt Frequency 56 Hz 50-60 Power consumption 08 watts 8 CF05 special coil or plugs with vent G1 / 8 DE85 core 0311-1015-260-00 Pressure range 1 - 40 bar Weight: kg / pc 0.595
3/2-way solenoid valve
2/2-way solenoid valve; servo-controlled Type 5281 5281 Generation 00 Unspecified Function A 2/2-way; Normally closed Nominal diameter 50.0 mm 50 Seal material NBR BB MS brass material GM89 line connection sleeve 2 G Coil size 6 40 mm Voltage 230 230 Volt Frequency UC direct and alternating current (AC / DC) Power consumption 09 watts 9 Special JA01 Terminal box with cable gland M20 x 1.5 (With approval PTB 00 ATEX 3119 X) + fuse (With approval PTB 01 ATEX 2064) MA02 Electrical connection via valve outlet MB05 cable outlet upwards PD53 Zulas. PTB 00 ATEX 2129X Ex m II T4 (without Kl. box) Ex em II T4 (with Kl. Box), II 2G, II 2D IP 65, Tu -30 ° C to + 60 ° C max. Surface temperature of 135 ° C, 9 W (only Individual installation) Pressure range 0,2 - 10 bar
More directional spool valve Type 0450 0450 Function H 5/2-way; In the rest position output 2 pressurized Nominal diameter 14.0 mm 14 GM84 line terminal G 1/2 sleeve Electromagnetic actuating EL. 32x32, air suspension Voltage 024 volts 24 Frequency UC direct and alternating current (AC / DC) JW12 cable length 5000 mm MW17 Vorsteurung Type 6014 PD49 Zulas. PTB 00 ATEX 2129 X Ex m II T5 (without Kl. Box), Ex em II T5 (with Kl. Box), II 2G, II 2D IP 65, Tu -30 ° C to + 60 ° C max Surface temperature of 100 ° C, 3 W (only Individual installation) Pressure range 1 - 10 bar Weight kg / St 1,599
2/2-way angle seat valve Type 2702 2702 Control function A closed with spring force Paths / positions 2 2 way / 2-position Nominal diameter 32.0 mm 32 Sealing material steel SS Material Stainless steel VA GM87 line terminal G 1 1/4 sleeve Drive Version C PA Drive, VA-threaded socket on the Control air connection Actuator size F DM 80 mm Interface Arm./Antrieb N4 nipple thread M50 x 2 (Standard DN 32) Control air connection 0000 standard control air connection or integral method of construction Special AF35 Short housing with metric. Threads on the Drive interface Pressure range 0 - 15 bar Weight: kg / pc 2,960
valve
5/2-way-pneumatic valve 32 mm
VALVE 6012 1,2 MM KL.-NR.001-01-04 20 MM 24 VOLT 4 WAT NL02
2/2-way proportional VALVE
3/2-way solenoid valve; direct acting Type 0323 0323 Function C 3/2-way; relieved in the rest position the output A Nominal diameter 20.0 20 NBR mmDichtwerkstoff BB MS brass material GM85 line connection G 3/4 sleeve Voltage 024 volts 24 Frequency DC DC Power 80 80 Watts Special BE01 magnetic drive 0131-1073-323-67 KR07 type plate: 24V = 80W KB 2s Pressure range 0 - 0.25 bar
DIG. Control electronics for PROPVENTILE
2/2-way piston control angle seat valve Type 2000 2000 Control function A closed with spring force Paths / positions 2 2 way / 2-position Nominal diameter 15.0 mm 15 Seal material PTFE EE Material RG gunmetal GM84 line terminal G 1/2 sleeve Drive Version B PA drive, MS-threaded socket on Control air connection Actuator size C DM 40 mm Special AF12 Short housing Pressure range 0 - 15 bar Weight: kg / pc 0.595
