160MP/4 TF RLS - Nord Norway (Norge) Sales

BRAND	Nord
Product	160MP/4 TF RLS
Description	motor
Internal code	IMP570040
Weight	1
Technical specification	mounted motor for the SK63 gearbox from the serial number 201060209-100 in IE3 version Engine speed 1,465 rpm Power (kW) 11,000 Voltage (V) 400/690 Frequency (Hz) 50 Efficiency class IE3 S1 operating mode Insulation class F Rated current 1 (AMP) 20.50 Rated current 2 (AMP) 11.80 Cosine 1 0.85 Engine position engine mounting WN Pos 016 Engine flange 300S Gearbox design. M1 Thermal motor protection PTC thermistor, 3x155°C Switching type: triangle. IP55 motor protection class Terminal box layer/ cable insert 1/I CE logo: yes. CCC logo No Mexico certificate NOM No UL no CSA no DoE CC no CSA ev no Alto Rendimento no Korea energy label no Backstop in the CCW motor Direction of rotation left Part number drive pinion 51470060 Engine gasket part number 51597060 Motor pinion mounted/included Assembled shade 7031 blue-grey Paint type solid color Painting instructions old paint finish 2 Basic painting instructions (2) Loose part engine gasket

Please Contact Us to Order to offer competitive prices and delivery time for Nord - 160MP/4 TF RLS motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
