| BRAND | S+S REGELTECHNIK |
| Product | 1301-1157-0130-200 |
| Description | Barometer/transducer for atmospheric air pressure |
| Internal code | IMP4760581 |
| Weight | 0.177 |
| Custom code | 90262020 |
| Technical specification | 24 V AC/ DC power supply (± 10%) Power consumption < 1 W at 24 V DC; < 2 VA at 24 V AC Burden Ra (ohms) = 25... 450 ohms with I variant Load resistance RL > 25 kOhm for U variant max. pressure ± 0.5% EW per year Output switchable 0 -10 V/ 4... 20 mA (via DIP switch) Circuit type 3-wire connection Current consumption < 45 mA Measurement ranges Multi-range switching with 4 switchable measurement ranges Pressure type atmospheric air pressure/absolute pressure Accuracy typical ± 0.4 kPa compared to calibrated reference device Zero-point offset ± 50 hPa Over -/under pressure 200 kPa Ambient storage temperature —35... +85 °C; Operating — 30... +75 °C, non-condensing Storage temperature —20... +50 °C Medium clean air and non-aggressive, non-flammable gases Signal filtering switchable 1 s/ 10 s (via DIP switch) electrical connection 2 or 3-wire connection 0.14 - 1.5 mm², via screw terminals cable fitting M 16 x 1.5; with strain relief, replaceable max. inner diameter 10.4 mm Long-term stability ± 0.5% EW per year hysteresis ± 0.1% EW Temperature drift ± 0.1% per °C EW Cable connection Plastic cable connector (M 16 x 1.5; with strain relief, replaceable, inner diameter 10.4 mm) or M12 connector (built-in plug, 5-pin, A-coding) according to DIN EN 61076-2-101 (optional on request) Temp. drift values ± 0.5% EW per 10 K housing plastic, UV-resistant, Material polyamide, 30% glass ball reinforced, with quick-release screws (slot/cross slot combination), Color traffic white (similar to RAL 9016) linearity ± 0.5% EW Case dimensions 72 x 64 x 37.8mm (Tyr 1) Humidity < 95% RH, non-condensing air protection class III (according to EN 60 730) Protection class IP 65 (according to EN 60 529) housing tested, TÜV SÜD, report no. 713139052 (Tyr 1) standards CE compliance, electromagnetic compatibility in accordance with EN 61326, according to EMC Directive 2014/ 30/EU |
Discover the superior quality and performance of the S+S REGELTECHNIK 1301-1157-0130-200 with Impexron GMBH in Norway (Norge). Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 1301-1157-0130-200 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 1301-1157-0130-200:
At Impexron GMBH, we offer the 1301-1157-0130-200 at competitive prices and with the fastest delivery times across Norway (Norge). Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH?
Get Your Quote Today! Ready to enhance your operations with the 1301-1157-0130-200? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply S+S REGELTECHNIK products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy 1301-1157-0130-200 by S+S REGELTECHNIK in Norway (Norge)?
You can purchase 1301-1157-0130-200 by S+S REGELTECHNIK from Impexron GMBH. We serve customers across Norway (Norge), offering competitive prices and reliable service.
What is the price of the 1301-1157-0130-200?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of S+S REGELTECHNIK in Norway (Norge)?
While we are not the official distributor or seller of S+S REGELTECHNIK in Norway (Norge), we source our products from reliable channels and offer you original S+S REGELTECHNIK equipment at competitive prices.
How can I access 1301-1157-0130-200 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 1301-1157-0130-200 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 1301-1157-0130-200?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
