101AG-AG3-M4-C1A-PKRRTBYYC1C4 - Sor Norway (Norge) Sales

BRAND	Sor
Product	101AG-AG3-M4-C1A-PKRRTBYYC1C4
Internal code	IMP4799513
Technical specification	ADJUSTABLE RANGE = 3-30 PSID OVERRANGE = 500 PSI PROOF = 1000 PSI ELECTRICAL RATING = 11 AMPS AT 250 VAC & 5 AMPS AT 30 VDC ------------------------------ 101 = NO. 101 PISTON AG = EXPLOSION PROOF/WEATHERTIGHT HOUSING, ALUMINUM, 1/2 INCH NPT (M) CONDUIT WITH WIRE LEADS, IP66 AG = DPDT, DEAD BAND FIXED, HERMETICALLY SEALED SWITCHING ELEMENT. 3 = NO. 3 SPRING M4 = 316L SS DIAPHRAGM/VITON O-RING C = 316/316LSST PROCESS CONNECTION 1A = 1/4 INCH NPT (F) PK = 2 INCH PIPE MOUNTING KIT RR = STAINLESS STEEL TAG WIRED TO HSG TB = EXPLOSION PROOF/WEATHERTIGHT JUNCTION BOX ALUMINUM 3/4 INCH NPT(F) CONDUIT CONNECTION YY = 316SS PIGMENT EPOXY COATING C1 = CERTIFICATE OF CALIBRATION*(REQUIRES A SET POINT.MUST SPECIFY DECREASING OR INCREASING PRESSURE) C4 = CERTIFICATE OF COMPLIANCE/CONFORMANCE

Please Contact Us to Order to offer competitive prices and delivery time for Sor - 101AG-AG3-M4-C1A-PKRRTBYYC1C4 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Norway (Norge) Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

More products of Sor

6NN-K5-N4-F1A

Static O Ring

701K1-U-P6-C-CS -X

SOR Ultrasonic Single Point Level Switch Typ: 701K1-U-P6-C-CS -X RANGE SINGLE POINT OVERRANGE PROOF ELECTRICAL RATING: 10 AMPS 250 VAC, 10 AMPS 30 VDC 701 = TIP SENSITIVE ULTRASONIC LEVEL SWITCH K1 = EXPLOSION PROOF/WEATHERTIGHT ALUMINUM HOUSING, NEMA 4/4X (IP65), CLASS 1, GRPS. C & D, DIV. 1&2, 3/4 INCH NPT(F) CONDUIT CONNECTION DPDT RELAY 10 AMPS 250VAC, 10 AMPS 30 VDC U = CONTROL FOR TIP SENSITIVE SENSOR P6 = POWER SUPPLY 24VDC C = METAL SENSOR CS = CSA CERTIFIED X= with 2” 150# flange, flange tapped 3/4" NPT

701K1-U-P6-C-CSC replaced by 701K1-U-P6-C-CS -X

SWITCH LEVEL

701K1-U-P8-C

Ultra-Sonic Level Switch Electronics

733A-F4C-T6-TTNCMR-X

LEVEL SWITCH,MODEL : 733A - F4C - T6 - TTNCMR - X / MAX LIQUID TEMP : 250 DEGREE F / 121 DEGREE CEN. / MAX PRESS : 15.5 BAR @ 93 DEG. / MICRO SWITCH : 220 VAC / HOUSING : EUROPEAN FLAME PROOF IIC T6 FLAME PROOF / IP65 / WITH 2 SETTING SWITCH

74V1-K118N4

DIFF PRESSSWITCH

74V1-K118-N4-C1A

pressure switch 30--0HG

74V1-K118N5

DIFF PRESSSWITCH

99V1-K45-S1-C1A

the pressure switch 200-1750PS

9BA-EB45-M1-C2A-PKTT

SWITCH, PRESSURE .200-1750 PSI.SET @1300 INC, 6000 PROOF, P-2704A/B DISCH. PRESS.

9NN-K45-M4-C2A-TT

PRESSURE SWITCH
