| BRAND | Burkert |
| Product | 00184690 |
| Description | 2/2-way solenoid valve |
| Internal code | IMP4037817 |
| Weight | 0.768 |
| Custom code | 84818079 |
| Technical specification | 6027-A02,0EPVAGM82-K-230/50-16 * MX14+NA38 Type 6027 Mode of action A 2/2-way; closed at rest Nominal width 02.0 2 mm Sealing material EP PTFE seat gasket + PEEK Material VA stainless steel Cable connection GM82 G 1/4 sleeve Spool size K 42 mm voltage 230 230 volts Frequency 50 Hz Power consumption: 16 watts Special feature MX14 Nominal pressure up to 100 bar NA38 Coil material insulating material class H pressure min 0 bar Pressure max 75 bar Pressure max/gas 100 bar KV 0.14 m3/h medium temp. min -40 °C medium temp. max 180 °C Ambient temp. min -40 °C Ambient temp. max 55 °C |
Discover the superior quality and performance of the Burkert 00184690 with Impexron GMBH in Norway (Norge). Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 00184690 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 00184690:
At Impexron GMBH, we offer the 00184690 at competitive prices and with the fastest delivery times across Norway (Norge). Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH?
Get Your Quote Today! Ready to enhance your operations with the 00184690? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Burkert products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
You can purchase :product by :brand from Impexron GMBH.We serve customers across the Norway (Norge), offering competitive prices and reliable service.
What is the price of :product?
For customised pricing and availability, please fill out our or give us a call. We are dedicated to providing solutions that align with your specific requirements.
While we are not the official distributor or seller of :brand in the Norway (Norge), we source our products from reliable channels and offer you original :brand equipment at competitive prices.
You can access catalogues, user manuals, and technical documents for :product on our website. Visit our resources section or contact us directly for specific documents.
We can assist you in contacting the manufacturer to ensure you receive the support you need.
2/2-way control piston diaphragm valve Type 2030 2030 Control function A closed with spring force Paths / positions 2 2 way / 2-position Nominal diameter 15.0 mm 15 Sealing material AB EPDM (Food Grade) Material PVC PV Line connection KM25 adhesive connection sleeve diameter 20mm Drive Version C PA Drive, VA-threaded socket on the Control air connection Actuator size D DM 50 mm Pressure range 0 - 8.5 bar
2/2-way control piston diaphragm valveType 2031 2031Control function A closed with spring forcePaths / positions 2 2 way / 2-positionNominal diameter 25.0 mm 25Sealing material AB EPDM (Food Grade)Material Stainless steel VAGM86 line connection socket G 1Drive Version C PA Drive, VA-threaded socket on theControl air connectionActuator size F DM 80 mmoutside NO01 glass bead blasted Ra 1.6 microns / Ra64 microinchesNo05 inner glass bead blasted Ra 1.6 microns / Ra64 microinchesPressure range 0 - 10 bar
2/2-way valve with isolating diaphragm for medium up to +100ºC
5/2-way pneumatic valve 10 mm
2/2, G1 / 2 ", brass, NBR, 24VDC, 0256 seri
3/2-way solenoid valve, direct-acting
3/2-way solenoid valve f. aggress. media Type 0121 0121 Mode of action F 3/2-way; distribution valve Nominal width of 6 mm 06,0 Seal material FKM FF Material PD PVDF (polyvinylidene fluoride) GM83 line terminal G 3/8 sleeve Voltage 230 230 Volt Frequency UC direct and alternating current (AC / DC) Power CE 60 Watt suit, 3 watt operation Special CZ05 Internal High Performance JC01 pressed-in tubular cables HO5RN-F3GO, 7 JW10 cable length 3000 mm Pressure range 0 - 2 bar Weight: kg / pc 0.320
solenoid valves
manometer which is part
2/2 way solenoid valve ½ PN1-40 BAR 230V 50-60 HZ 8W
2/2-way solenoid valve; servo piston Type 5404 5404 Action of B 2/2-way; Normally open Nominal diameter 12.0 mm 12 Sealing material EB PTFE seat seal NBR + MS brass material GM84 line terminal G 1/2 sleeve Coil size 5 32 mm Voltage 230 230 Volt Frequency 56 Hz 50-60 Power consumption 08 watts 8 CF05 special coil or plugs with vent G1 / 8 DE85 core 0311-1015-260-00 Pressure range 1 - 40 bar Weight: kg / pc 0.595
3/2-way solenoid valve
2/2-way solenoid valve; servo-controlled Type 5281 5281 Generation 00 Unspecified Function A 2/2-way; Normally closed Nominal diameter 50.0 mm 50 Seal material NBR BB MS brass material GM89 line connection sleeve 2 G Coil size 6 40 mm Voltage 230 230 Volt Frequency UC direct and alternating current (AC / DC) Power consumption 09 watts 9 Special JA01 Terminal box with cable gland M20 x 1.5 (With approval PTB 00 ATEX 3119 X) + fuse (With approval PTB 01 ATEX 2064) MA02 Electrical connection via valve outlet MB05 cable outlet upwards PD53 Zulas. PTB 00 ATEX 2129X Ex m II T4 (without Kl. box) Ex em II T4 (with Kl. Box), II 2G, II 2D IP 65, Tu -30 ° C to + 60 ° C max. Surface temperature of 135 ° C, 9 W (only Individual installation) Pressure range 0,2 - 10 bar
More directional spool valve Type 0450 0450 Function H 5/2-way; In the rest position output 2 pressurized Nominal diameter 14.0 mm 14 GM84 line terminal G 1/2 sleeve Electromagnetic actuating EL. 32x32, air suspension Voltage 024 volts 24 Frequency UC direct and alternating current (AC / DC) JW12 cable length 5000 mm MW17 Vorsteurung Type 6014 PD49 Zulas. PTB 00 ATEX 2129 X Ex m II T5 (without Kl. Box), Ex em II T5 (with Kl. Box), II 2G, II 2D IP 65, Tu -30 ° C to + 60 ° C max Surface temperature of 100 ° C, 3 W (only Individual installation) Pressure range 1 - 10 bar Weight kg / St 1,599
2/2-way angle seat valve Type 2702 2702 Control function A closed with spring force Paths / positions 2 2 way / 2-position Nominal diameter 32.0 mm 32 Sealing material steel SS Material Stainless steel VA GM87 line terminal G 1 1/4 sleeve Drive Version C PA Drive, VA-threaded socket on the Control air connection Actuator size F DM 80 mm Interface Arm./Antrieb N4 nipple thread M50 x 2 (Standard DN 32) Control air connection 0000 standard control air connection or integral method of construction Special AF35 Short housing with metric. Threads on the Drive interface Pressure range 0 - 15 bar Weight: kg / pc 2,960
valve
5/2-way-pneumatic valve 32 mm
VALVE 6012 1,2 MM KL.-NR.001-01-04 20 MM 24 VOLT 4 WAT NL02
2/2-way proportional VALVE
3/2-way solenoid valve; direct acting Type 0323 0323 Function C 3/2-way; relieved in the rest position the output A Nominal diameter 20.0 20 NBR mmDichtwerkstoff BB MS brass material GM85 line connection G 3/4 sleeve Voltage 024 volts 24 Frequency DC DC Power 80 80 Watts Special BE01 magnetic drive 0131-1073-323-67 KR07 type plate: 24V = 80W KB 2s Pressure range 0 - 0.25 bar
DIG. Control electronics for PROPVENTILE
2/2-way piston control angle seat valve Type 2000 2000 Control function A closed with spring force Paths / positions 2 2 way / 2-position Nominal diameter 15.0 mm 15 Seal material PTFE EE Material RG gunmetal GM84 line terminal G 1/2 sleeve Drive Version B PA drive, MS-threaded socket on Control air connection Actuator size C DM 40 mm Special AF12 Short housing Pressure range 0 - 15 bar Weight: kg / pc 0.595
00178676 TYP 2000 NENNWEITE 25,0
2/2-way piston control angle seat valve Type 2000 2000 Control function A closed with spring force Paths / positions 2 2 way / 2-position Nominal diameter 25.0 mm 25 Seal material PTFE EE Material RG gunmetal GM86 line connection socket G 1 Drive Version B PA drive, MS-threaded socket on Control air connection Actuator size E DM 63 mm Special AF12 Short housing MS74 mounted V-ANTR Pressure range 0 - 11 bar Weight: kg / pc 1,566
valve seat tilted 2/2,TYPE : 2000
00178695 TYP 2000 NENNWEITE 40,0
2/2-way piston control angle seat valve Type 2000 2000 Control function A closed with spring force Paths / positions 2 2 way / 2-position Nominal diameter 40.0 mm 40 Seal material PTFE EE Material RG gunmetal GM88 line terminal G 1 1/2 sleeve Drive Version B PA drive, MS-threaded socket on Control air connection Actuator size F DM 80 mm Special AF12 Short housing Pressure range 0 - 9 bar Weight: kg / pc 3,100
2/2-way angle globe valve
Type AC10 AC10 Interface. Valve / coil U3 Zentralverschraubt, core diameter 10.6 mm, universal Coil size 5 32 mm Coil winding 19ab
024/DC/04 Typ AC07 AC07 U2 CENTRAL SCREW, CORE DIAMETER 7 MM UNIVERSAL 20 MM 21AA
00179938 5/2-WEGE-PNEUMATIKVENTIL 10 MM 6525
Mode of operation H 5/2-way; At rest, output 2 pressurized Nominal width 04,0 4 mm Cable connection 1 FM14 flange pattern type 6525 Line connection 2 0000 not available Operating mode Z electropneumatic based on type 6144 Set spool size 0 type-specific voltage 024 24 volts Frequency BA battery power Power consumption AA 0.8 Watt JB17 Right PIN positive pole JF80 Rectangular Plug Connector 5.08 mm, 2 Pin Pressure range 2.5 - 10 bar Weight: kg/st 0.025
